2022 BDNY

Did you miss this year's BDNY? No worries, we have you covered! Here are some of the products we found interesting for various projects. Mostly glass works and metal works for high-end residentials, lobbies, and large decoratives (mostly pendants) for natural rustic material suitable for hospitality projects!

LUCIFER LIGHTING

Today we looked at the LUCIFER LIGHTING updated track lights, eco line downlights, and new anodized finishes (beautiful!).

ATOMOS:

  • a very affordable downlight. Good lead time of 1 to 3 weeks

  • A huge plus is that they have trimless millwork at an affordable price point (haven't seen many competitors offering this option). Round and square trim, available as new construction and remodel housing.

  • The adjustable model has a max 30-degree tilt.

  • The wall washer has a small kicker to push the light out of the ceiling.

  • Note: For the wall washer, the square trim has a better performance and higher output compared to the round trim. 1000lm vs. 920lm for the round trim. The round has a 1:1 ratio, but the square allows further spacing. For the round trim, we noticed a round spread on the side so be careful with spacing.

We also looked at a new zoom fixture, rotating the optics to adjust the spread. It only moves from 20 to 40 degrees, and had a large field angle, so it may not be a good option for art lighting.

TRACK HEADS:

  • New Alumina finishes with four (4) matt and four (4) brushed options (a new anodizing process). They looked gorgeous!

  • Warm dim is available in different outputs in the remote driver model. It's also available in medium size with an integral driver, BUT there is a wattage restriction. It's a YES, but $$$

  • Integral ELV driver down to 5% to 2%. There is a restriction with output. Max 1300lm delivered 900 for medium size.

  • The remote driver version goes up to 2300lm.

  • The nice thing is that their 120V medium track head seats flush to the track with an integral driver.

  • Monopoint has a mud-in ring for flush mounting the slim canopy.

  • The standard stem length is 1.4", but it can be ordered up to 12". They are moving toward making their new track stem (on the center) the standard. Updating T2 to this.

  • Large-size wallwasher track offers typical 3ft spacing for a 15ft ceiling. They have a little light leak on the ceiling.

  • Their tack and monopoint accept 2 accessories. They can provide a cross baffle, depending on the project size! Ask

  • They are looking out to expand their track system toward two circuits, pendant mount, surface, and recessed!

LUCENT LIGHTING

We looked at some of the new updates to the LUCENT Lighting fixtures

2" Plus Fixture: IC rated fixed downlight, offered with adjustable tray to access the terminal box (driver)

Mini wall-washer: 1.65” aperture - 1:1 spacing - Nice wash from the edge of the ceiling

absolutely favorite such beautiful from all the way from the edge of the ceiling to the floor and further

Micro Focus Accent Light: Great accent light specifically for millwork but remembering the thicker the millwork, less adjustability - Tunable Mini looked very bright and powerful.

  • CREE LED chips for the tunable white

  • Xicato is the standard LED chip

  • LUMENEDIX LED chip is used for RGBW

InGround 2.36" circular: walk over recessed uplight with 8°, 15°, 25°, 30°, & 10°x45° beams, fixed 7-degree tilt - Available accessories are elliptical beam effect, square beam, & honeycomb louver.

Monopoint option comes in recessed and surface mount - 94 CRI, 1800lm, four beams from 17 to 50 degrees - Accept x2 accessories.

Black with Copper finishes in the trim - we liked the copper finish.

14mm option the smallest - soon in the USA

Beautiful recessed wall fixture - We looked at InWall 50 Square with backbox - Great sharp distribution and clear cut-off line - If requested, they have a film to soften the distribution

Available in different beams and sizes. All are outdoor-rated except the bronze finish option.

Reference Project:

Track fixture + spotlight: Restoration Hardware stores.

Asymmetric Lighting: Luice hamilton penthouse, wester street, water place in London

N8 LIGHTING

Today we looked at the new updates to the N8 LIGHTING downlights, including the 800 Series NEW tunable white option.

The adders for warm-dim and tunable are just $20 and $80. We also reviewed the smooth dimming curve in warm dim and standard white with N8’s DIM1 standard driver.

The mono-point now comes with four (4) stem lengths and round or square shapes, installed with a 4” Jbox with an integrated driver. A new remote driver option comes with a 1” canopy. (NOT AVAILABLE AS TRIMLESS BUT it’s very thin, just 1/8”. ) Available narrow spots are: A true 10 degree beam (not in WD), 15 degree (available with WD), NOT AVAILABLE in 2700k BUT this CCT can be achieved with colored lens accessories.

All the downlights have Cree LED chip except the mono-points.


LUCIFER Lighting

Today we looked at the new and upgraded products from Lucifer Lighting:

Fraxtion 3: NEW - 3” aperture round and square trimless wood downlight; installed in a thrilling up to 2.125" thickness (UPDATE: doubled the acceptable thickness).

  • Available with shallow housing, improved aiming focus (no tools necessary) - 40-degree tilt.

  • Very clean trimless wood bevel available in matt black and shiny bronze - Double wiper system to hold the trim in place! Very easy to remove

  • NEW - More integral driver options: 0-10V to 1% & Lutron Ecosystem to 0.1%.

  • NEW CCTs: Static 2200K, WD: 2700K to 1800K, Tunable White

  • NEW: 10-degree optic is available across the board (not available in WD and 2200K, comes with a smaller dedicated LED, therefore it has lower lumen package- it is field exchangeable for larger beam spread- however, we can’t go down from larger optics to 10 degree.

  • 10-degree use LUMINUS LED and the rest beam spreads use CITIZEN LED Chip.

CY4 Cylinder: NEW - 4.9" aperture, max 4500lm, 15 degrees up to 60 degrees beam options, adjustable and lockable in place, interchangeable optic. Wet rated except in up/down model. Available with surface conduit (CMJB), Cylinder & Squilinder

NEW: Square shaped surface conduit & Fixed body wall wash

Here are also some interesting reference photos for STELLR fixture that we looked at before.

3G LIGHTING

We looked at the updated and new product families today.

MADISON Family:

Micro MADISON Slot: 3.8” wide continuous runs slot with adjustable and lockable Individual fixture heads; up to 1000lm output. The Slot System is available in 4.8” and 5.8” could accommodate camera, speaker, other equipment.

NEW: Madison Slot in recessed and pendant version available as standard.

NEW (Q2) in Downlight family: Wood trim for their 3.3” and 4.5” round & square beveled downlights

Cylinder family: 3.3” aperture model is the NEW addition to the current 4.5” aperture; available in 7” (up to 2200lm) & 11” (up to 4000lm) with NEW Madison Double Gimble. The 3.3" is available in round and square, beveled trim up to 3000lm and with integrated Micro Madison up to 1000lm; Available in tunable and warm-dim.

Another NEW update is the adjustable cylinder in 3.3”, 90-degree tilt and 360-degree rotation, up to 3000lm. Stem mounting will be an option in new future (in-progress)

ZOIE: NEW beam spreads of 10, 15, 35, and 60 degree optics as standard. up to 200lm/cell, Osrom LED Chip

  • Zoie recessed wall wash: 1.14” wide, 4”, 8”, and 12” lengths with NEW integrated louver for better glare control,

  • Zoie Continuous run pendant: NEW is 4’ in length, matching the output options to LINEA (250, 500, 750, and 1000lm); modifiable with a programable driver.

  • NEW (Q2): Surface mounted Zoie continuous run and could be specified in 1FT increment starting from 1FT instead of current 4FT starting length.

NEW: Now LINEA and ZOIE could be mixed in a single continuous run.

LINA Grazer series: NEW 35 degree adjustability.

Grazer products are available in tunable white and RGB.

Standard down to 1% dimming.




LANDSCAPE FORMS

LANDSCAPE FORMS

Located in Michigan with over 10 years of experience in lighting. They are known for their furniture and their integrated lighting solutions into furniture. They are concentrated in the following categories:

  • Area lighting

  • Wall & Surface Mount Lighting

  • Catenary & Pendant Lighting

  • Floor Lighting

  • Path lighting, bollards and wayfinding

ALOCTT is one of their popular pole lighting fixtures, available in 12ft, 14ft, 16ft, 20ft, and 32ft, mostly used in compasses, parks, parking lots.

SKYLINE Bollard is their shortest bollard fixture. It comes in 15" and 32" tall.

RECENT PRODUCTS:

MOTIVE: Bringing the look of area lighting 10-12ft performance path lighting They could design the illuminated part facing out. (All the photos are shown in 3000K)

The standard CCT options for this family are 2700K, 3000K, and 4000K. The 2700K is not available other fixtures as standard.

The Floor Lamp Motive is available as hard wired or plug-in with a 10ft long cord. This fixture is fairly stable with over 50 pound weight. It could be screed to the ground for more stability.

TUMBLER: comes as pole mounted with different configuration single or multi heads, also available in catenary and pendant mount. Available as a frosted and clear lens. This fixture could be daisy-chained. Single COB LED chip is an option for all the categories in this family. It offers better shielding. All the COB models are Dark Sky Compliance.

SLOPE: Pole and wall mount single and double head fixture; also available in the retrofit.

MODIFIED PRODUCTS: They are open to customization with a dedicated department for that.

For dimming, all the fixtures have an integral driver with 0-10V dimming down to 10% as standard. Options for going below 10% is also an option.

XAL + ARMSTRONG Ceiling

Today We looked at two new recessed linear fixtures, compatible with ARMSTRONG ceiling.

PANO

Low profile recessed fixture available in 2”, 3.25”, and 5.25” wide; compatible with standard length Armstrong’s Woodworks Grille, Woodworks Grille Tegular 9/16”, Woodworks Linear Veneered Panels, and Woodworks Linear Solid Wood Panels.

This fixture only comes in 2’, 4’, and 8’, the same length as the Armstrong panels. For a continuous run, there will be a 1inch reveal between fixtures.

Wider aperture is preferred for use with the wooden gride. No extra hanging wires are needed since there are heavy-duty grids in the Armstrong ceiling structure. Simply fastening brackets needed to grip and snap on to the structure.

This fixture has a remote driver which could also be mounted directly on the back of the fixture (like the integrated driver).

Available lengths for integration into Grille Tegular ceiling are 2’ and 4”, matching the grid length.

LENO

A 3 ⅜" wide recessed fixture, installed from below with easy snap-in installation; great for applications with minimal clearance above the ceiling.

This fixture features plug and play wiring system (not available in PANO).

It’s compatible with Armstrong 9/16" Suprafine, Silhouette, Interlude, 4" TechZone.

The start and end fixtures in the continuous run are slightly shorter to accommodate the ceiling grids.

Armstrong collaborated with AXIOM (3rd party) company for cove and perimeter lighting with prefabricated drywall kit

For lengths greater than standard runs, XAL offers black cover for ends. Although for plaster-in, end to end run, the BASO fixture is a better option. It comes in 1.5”, 2.5”, 4” widths. It’s slightly taller without a plug& play option

BARN LIGHT ELECTRIC

Barn Light Electric gave a quick webinar on their new products recently. We were excited to see their new expansion into more modern forms and turned-wood expressions. These were truly beautiful pieces! Barn Light’s ease of customization and American-made local factory makes them a go-to for us.

Selux

Today Selux hosted a webinar to fill us in on some of their new products.

ELO Wood

  • Selux now works with Structura to create this wood fixture. This is a multi-layered wood that is treated and finished.

  • These products have a 50 year warranty above ground, and a 25 year warranty below ground. This warranty covers rotting, cracking, and finish fading.

  • It is a marine grade finish.

  • Everything is accessible from the bottom of the fixture.

  • Currently, the fixture comes with 3 rows of LEDs but can be customized to 2 rows if needed.

M36 Wall Washer

  • This is their new wall wash fixture. It is much more effective than using their A20 optic.

  • The bottom of the fixture protrudes just slightly.

  • It is suggested that it is 18” from the wall it is lighting, and 9” from any perpendicular wall.

  • This fixtures utilizes their M36 housing.

  • If this is turning a corner, the corners must be filled with blanks.

  • This fixture comes in a black of white finish.
